- 240×240 Resolution: Thermal imaging camera has 240*240 resolution for clearer real-time viewing and capturing of photos. 50mk thermal sensitivity allows visualization of temperature differences, helping you to detect problems early and diagnose them reliably. 25Hz high frame rate ensures a smooth on-screen viewing experience during anomaly detection.
- 15 color palettes: There are 15 color palettes that give you the flexibility to choose the most suitable palette according to different detection scenarios and purposes.
- Highly accurate measurements: The camera measures temperatures from -20°C to 550°C (-4°F to 1022°F). Industrial thermal imaging cameras can adjust the distance to the object and fine-tune the emissivity setting for specific materials, ensuring more accurate temperature measurements on a wide range of substances such as cement and bricks.
- 2.4-inch TFT color screen: This thermal camera features a 2.4-inch 320 x 240 TFT full view color screen for easier viewing. It can automatically identify the maximum, minimum and center temperatures, which are displayed in the upper left corner of the screen. Makes it easier for you to see 3 pieces of data at the same time.
- High/Low Temperature Alarm: The camera has a high/low temperature alarm that sounds when the temperature exceeds or falls below the set data.
- Dual injection molding process: This thermal imaging camera is made of dual injection molding process, which provides high precision and durability, and is resistant to abrasion, scratches and drops. It is also designed with a standard tripod hole to support the use of a tripod to assist in inspection work.
Features:
240*240 infrared resolution, more clear and more details
With 15 kinds of pseudo-colors, you can flexibly choose the right color palette
℃/℉/K selectable: -20~550℃/-4~1022℉
Sufficient memory capacity, capable of storing 30,000 images
With rechargeable Li-ion battery, longer battery life
Specification:
Display: 2.4 inch TFT LCD
Sensor Type: Vanadium Oxide (VOx) Microbolometer
Response band:8-14pm
Thermal image resolution:240*240 pixels
Noise Equivalent Temperature Difference (NETD):≤60mK(@25℃,F#1.0)
Spatial resolution (IFOV): 8.89mrad
Frame rate:25Hz
Imaging lens focal length:1.35mm
Temperature measurement resolution: 0.1℃
Temperature measurement focal length: 0.3m-3m adjustable
Temperature range: -20℃-550℃
Temperature measurement accuracy: ± 2 ℃
Temperature measurement unit: degrees Celsius, degrees Fahrenheit, Kelvin
Pseudo-color: white heat, black heat, fusion 1, rainbow, fusion 2, iron red 1, iron red 2, sepia, color 1, color 2, ice and fire, rain, green heat, red heat, dark blue
Display resolution: 320*240
Image storage: 30000
Size: 193.4*59.4*77.4mm
Weight: 277g
Package Contents:
Infrared thermal imager
EVA storage bag
USB charging cable
Instruction manual
Silicone lanyard
- Product Dimensions : 7.61 x 2.34 x 3.05 inches; 9.77 ounces
- Batteries : 1 Lithium Ion batteries required. (included)
- Date First Available : July 29, 2024
- Manufacturer : BSIDE
